We assemble and install LED screens for indoor and outdoor and in any size, anywhere in Spain.
Programmable on / off timer
Possibility of texts superimposed on scenes
Brightness, contrast and range control
Preview of scenes on PC
App for IOS and Android for use from mobile
GIF Animation
Text
Clock, stopwatch, * temperature,* humidity (*) Optional (NOT included)
| LED type | SMD (3 RGB LEDs in the same package) |
| Cabinet size | 96 x 64 cm and 96 x 96 cm. (Width by height) |
| Cabinet material | Steel, aluminum or cast aluminum |
| Pitch (Distance between LEDs) | 0,9, 1,25, 4 and 5 mm indoor 4, 5, 8 and 10 mm outdoor |
| Viewing distance Greater than or equal to the PITCH | PITCH 4: greater than or equal to 4 m PITCH 5: greater than or equal to 5 m PITCH 8: greater than or equal to 8 m PITCH 10: greater than or equal to 10 m |
Rear maintenance
Front bonnet maintenance
Front maintenance
Turnkey
We offer a “turnkey” service. We take care of everything: prior visit, screen manufacturing, bearing structure manufacturing, installation anywhere in the country, commissioning and maintenance.
Warranty:
2 years on all equipment.
Certificates.
All the elements of our screens have a CE certificate. All our LED modules are RoHS certified and ISO 9001, ISO 14001 and ISO 18001 certified.
Insurance :
All our products and facilities are covered by our civil liability insurance of 1,200,000 €uros of coverage.
Quality Control
All screens are mounted before being sent and are left running between 48-72 hours.
Engineering project
For all those major facilities and / or with technical complexity in their attachment or moorings, we provide an engineering project endorsed by the corresponding association.
| IP grade | PROTECTION AGAINST SOLID BODIES | PROTECTION AGAINST MOISTURE |
| INTERIOR SCREENS IP22 | GRADE 2: Protection against solids + 12.5mm | GRADE 2: Protection against dripping water (15º inclination 3-5 mm 3 minutes) |
| OUTDOOR SCREENS IP54 | GRADE 5: Complete protection against contact, dust sedimentation | GRADE 4: Equipment 100% protected against water spray 10 l / minute with 80-100Kn / m2 pressure |
Weight
Indoor screens 26Kg / m2
Outdoor screens 42Kg / m2
Connection
Via RJ45 data cable (always included)
Via Wi-Fi or 4G (optional)
Content Management Software
HD Player.
Included in all systems, free of charge
